Page 14 of 58 Pages
OVERALL DIMENSIONS DRAWING FOR THE 3150 / 3170 ELV
Note:
The dimensions A, B and C are different for the models 3150 and 3170, as
indicated below
TYPE A B C
3150
1165 780 530
3170
1345 960 710
