Page 16 of 58 Pages
OVERALL DIMENSIONS DRAWING FOR THE 5050/ 5075 ELV
Note:
The dimensions A, B and C are different for the models 5050 and 5075, as
indicated below
TYPE A B C
5050
1440 780 503
5075
1670 1010 733
