3.7 Loading Capacities
3.7.1 Erlenmeyer Flasks
SIZE 2540 3150 3170 3850 3870 5050 5075
250 ml 2 x 4 3 x 7 3 x 7 2 x 12 3 x 12 2 x 21 3 x 21
500 ml 1 x 2 2 x 4 3 x 4 2 x 8 3 x 8 2 x 14 3 x 14
1000 ml 1 2 x 2 3 x 2 1 x 5 2 x 5 2 x 8 3 x 8
2000 ml 1 1 2 x 1 1x2 2 x 2 1x5 2 x 5
3000 ml 1 1 2 x 1 1 2 x 1 1x4 2 x 4
5000 ml — 1 1 1 1 1x2 1x2
3.7.2 Medium Flasks (Schott)
SIZE 2540 3150 3170 3850 3870 5050 5075
250 ml. 2 x 7 3 x 11 3 x 11 2 x 19 3 x 19 2 x 32 3 x 32
500 ml 1 x 4 2 x 7 3 x 7 2 x 12 3 x 12 2 x 21 3 x 21
1000 ml 1x3 1 x 5 2 x 5 1 x 8 2 x 8 2 x 15 3 x 15
2000 ml 1 31x2 2 x 2 1x4 2 x 4 1x8 2 x 8
5000 ml 1 1 1 1 1 1x4 2 x 4
3.8 Utility
Utility Power
Recommended
Circuit Breaker
Power
Supply
2540
1Ph, 230V/50/60Hz 20A
3150/70
1 or 2 Ph, 230V/50/60Hz 25A
3850/70
3 Ph, 208V/50/60Hz 25A
3850/70
3 Ph, 230V/50/60Hz 25A
3850/70 with switching box
1 or 2 Ph, 230V/50/60Hz 30A
3850/70, 5050/75
3 Ph, 400V/50/60Hz 20A
5050/75
3 Ph, 208V/50/60Hz 30A
5050/75
3 Ph, 230V/50/60Hz 30A
5050/75 with switching box
1 or 2 Ph, 230V/50/60Hz
45A
Compressed Air (ELVC models
only)
1/2" 3-4 Bar
Tap water
1/2", 2-3 Bar
Mineral free water
1/2", 2-4 Bar
Drain
Withstanding temp. of 80°C
Attention:
The electrical net must be protected with a current leakage safety relay.
The electrical network must comply with local rules or regulations.
