MX/MZX
17A-04-S
17 10/09
PAGE 10 of 40
3.3.1 ENTERING PASSCODES
In order to avoid repetition, however, the general procedure
for entering a PASSCODE is described as follows:
i) Press F3 (Passcode), enter your ID (press
F5 ‘Enter’ if the ID has only one digit),
then enter your Passcode (press F5 ‘Enter’
if the ID has less than 6 digits).
3.4 POINT DEFINITIONS
Real point - A physical input/output point
Pseudo point - A software derived fault number
eg, Communications Fault or
RAM Fault
Timer - Point activated by user
(MZX CONSYS) configured timer
Menu - Up to 10 points configured for
specific site functions
3.5 VALID VALUES
The following are values which may be entered for each
option:
‘*’ depending on the configuration 16/32/40/80/120/160/
200 or 240 zones.
Panel Number 1 - 99
Zone Number 1 - 240*
Sector Number 1 - 240
RBus Number 0 - 15
Real Point
Pseudo Point
XBus Point
1 - 24
1 - 8
1 - 96
Local I/O
Real Point
Pseudo Point
IOBus point
Timer Point
Menu Point
1 - 18
1 - 61
1 - 24
1 - 10
1 - 10
* Key OFF F1 key ‘View’
Engineer
Engineer
Supervisor
Enable
Key
Lamp/Buzzer/LCD Test* ✔✔ OFF
Unrestored Events ✔✔ OFF
Information Text ✔✔ OFF
View Events (Scrolling) ✔✔ OFF
MAIN MENU ✔✔ ON
Accept Events ✔✔ ON
View Status ✔✔ ON
Isolate/De-Isolate ✔✔ ON
Time/Date ✔✔ ON
Set time/Date ✔✔ ON
Summer/Winter ✔✔ ON
Event Log ✔✔ ON
View Event Log ✔✔ ON
Print Event Log ✔✔ ON
Filter ✔✔ ON
View/Print Data ✔✔ ON
Points Isolated ✔✔ ON
Points Untested/Failed ✔✔ ON
Point Values ✔✔ ON
View Faults ✔✔ ON
Loop Point Count ✔✔ ON
Forced Points ✔✔ ON
Active Points ✔✔ ON
By Function* ✔✔ OFF/ON
Service ✔✔ ON
Walk Test ✔✔ ON
Maintenance engineer ✔✔ ON
Fire Alarm Cycle Count ✔✔ ON
Maintenance Request ✔✔ ON
Battery Test ✔✔ ON
Software Initialisation Count ✔✔ ON
Project Numbers ✔✔ ON
Software Versions ✔✔ ON
Menu points ✔✔ ON
Diagnostics ✔✔ ON
Force Device Output ✔✔ ON
Force Device Input ✔✔ ON
Shutdown/Restart ✔✔ ON
Single device poll mode ✔✔ ON
Change Address ✔✔ ON
Calibrate DDM800 ✔✔ ON
Restart System ✔✔ ON
Switches ✔✔ ON
Fast Fault Mode ✔✔ ON
Rate of Rise Processing ✔✔ ON
Fast Logic ✔✔ ON
Noisy Device ✔✔ ON
Detector Power Up ✔✔ ON
Configuration ✔✔ ON
Change Text ✔✔ ON
Insert Point ✔ ON
Delete Point ✔ ON
Modify Point ✔ ON
Auto Configure ✔ ON
Table. 1 Menu Options and Access Levels
