The following lists the error code descriptions:
1 - Unknown Error
It was determined that there was an Error with the
associated Point, but it was unable to be classified.
2 - Multiple Devices at Address
It was found that more than one Device responded at
the address specified.
3 - Logical Zone Overflow
While adding Points for all the new devices found,
thelimit for the maximum number of Points allowed
in a Logical Zone was reached. All new Devices
found after this limit was reached will be assigned
this error and will not be added.
4 - Device Not Supported
For a new Point to be added by Auto-configuration,
any Device found must be allocated an entry in the
'Device Uses Configuration Table'. If a newly
discovered Device does not have such an entry, it will
be assigned this error code.
5 - Device Use Not Supported
For a new Point to be added by Auto-configuration,
any Device found must be allocated both an entry in
the 'Device Uses Configuration Table' and have at
least one 'Use' enabled. If a newly discovered Device
is found in the 'Device Use Table' but does NOT have
the appropriate 'Use' enabled, it will be assigned this
error code.
6 - Invalid Address
A new Device was found to be responding at an
Address not currently valid (e.g. '0')
7 - Too Many Points on Loop
While adding in Points for all the new devices found,
the limit for the maximum number of Points allowed
on a Loop was reached. All new Devices found after
this limit are assigned this error, they will not be
added.
MX Panel
Wed, 01-Mar-00
14:15
Company Name
General
Back
Autoconfiguration
Points failed
Panel : 00
Loop : B
Point : 001
Device Type:
Error : 008
Point 001/001
8 - Multi-Channel Device
There is currently only limited support for Multi-
Channel Devices, any conflict due to a known Multi-
Channel Device type will receive this error code. Note
unless the Device has an entry in the 'Device Uses'
table, Auto-Configuration will not be aware that it is in
fact a Multi-Channel Device, and Error 4 ('Device Not
Supported') will be assigned instead.
9 - Change of Device Type Not Allowed
If the Auto-Configuration option 'Only add new' is
selected, then it is not possible to change the Device
Type of an existing, configured Point.
3.15 TEST BUZZER/LEDs/DISPLAY
Selecting option 9 from the Main menu causes the following to
happen for approximately 2 seconds:
The LCD Backlight to extinguish
All LEDs to illuminate
Internal buzzer to pulse
WARNING:
BEFORE LEAVING SITE, ANY FORCED
INPUT/OUTPUT MUST BE UNFORCED.
FAST FAULT, RATE OF RISE PROCESSING
OR SINGLE DEVICE POLL MODE MUST BE
SET TO THEIR DEFAULT SETTINGS.
Any non-standard settings will display
‘COMMISSIONING’ on the bottom line of the LCD.
