Pressing Iso&For (F2) will display the following screen:
3.12.8 BY FUNCTION
Select option 8 from the View/Print Status Menu. The
following type of screen will be displayed:
Screens for options 2, 3, 4, 5 and 6 are the same type as for
option 1 Fire Inputs.
3.12.8.1 FIRE INPUTS
Select option 1 from the By Function menu, the following
screen will be displayed:
MX Panel
Wed, 21-Aug-07
08:01
Company Name
General
Back
Active Points
Isolated Forced pts
Total : 0
All Act
Print
MX Panel
Wed, 21-Aug-07
08:01
Company Name
General
Back
By Function
1 - Fire Inputs
2 - Non-Fire Inputs
3 - All Loop O/Ps
4 - Sounders
5 - Protection Eqp.
6 - Plant Equipment
MX Panel
Wed, 21-Aug-07
08:01
Company Name
General
Back
Fire Inputs
1 - Active
2 - Fault
3 - Isolated
Select option 1 from the Fire Inputs menu, the following
screen will be displayed:
Select option 2 from the Fire Inputs menu, the following
screen will be displayed:
Select option 3 from the Fire Inputs menu, the following
screen will be displayed:
MX Panel
Wed, 21-Aug-07
08:01
Company Name
General
Back
Active Fire IPs
Panel: 1
Page : 0/ 0
MX Panel
Wed, 21-Aug-07
08:01
Company Name
General
Back
Fire IPs in Fault
Panel: 1
Page : 0/ 0
MX Panel
Wed, 21-Aug-07
08:01
Company Name
General
Back
Isolated Fire IPs
Panel: 1
Page : 0/ 0

Tyco MX Series Specifications

General

Type	Fire Alarm Control Panel
Output Voltage	24 VDC
Protection Class	IP30
Networkable	Yes
Operating Temperature	0°C to 49°C
Storage Temperature	-10°C to +60°C
Input Voltage	120/240 VAC, 50/60 Hz
