All 250 addresses may be displayed using the ‘>>) key.
The connection detail of each point is shown by the
following symbols:
Function key F2 scrolls through the loop.
3.12.5.2 SCAN
Press the ‘Scan’ key (F3), the following type of screen will
be displayed:
The points are shown which were detected from both sides
(Left/Right).
They are displayed as follows:
Function key F2 scrolls through the loop.
o OK: point connected, configured and identified
(eg, point 33 and points 60 to 64)
Point was configured (in MZX CONSYS) but
not connected or identified (eg, point 21)
Point was not configured but connected (eg,
point 6)
Empty (not used)
OK: detected from both sides (eg, points 33 and
82)
Only detected from left side (eg, points 4 and 21)
Only detected from right side (eg, 60 to 64)
MX Panel
Thu, 26-Jul-07
14:15
Company Name
General
Back
Loop Point Counters
>>
Left / Right Scan
Loop : A
Point 0123456789
0 : ....l.....
10 : ..........
20 : .l........
30 : ...*......
40 : ..........
50 : ..........
60 : rrrrr.....
70 : ..........
80 : ..*.......
3.12.6 FORCED POINTS
Select option 6 from the View/Print Status Menu. The
following type of screen will be displayed:
This option is view only. Pressing F2 will display any
forced outputs.
3.12.7 ACTIVE POINTS
Select option 7 from the View/Print Status Menu. The
following type of screen will be displayed:
Pressing Iso&Act (F2) will display the following screen:
Input:
Total: 1
Zone 001 A001
CO Device
MX Panel
Wed, 01-Jan-99
00:01
Company Name
General
Back
Forced Points
Output
Print
MX Panel
Wed, 21-Aug-07
08:01
Company Name
General
Back
Active Points
Current active pts.
Total : 0
Iso&Act
Print
MX Panel
Wed, 21-Aug-07
08:01
Company Name
General
Back
Active Points
Isolated active pts
Total : 0
Iso&For
Print
To Next Page
