MX/MZX
17A-04-S
17 10/09
© 2009 Tyco Safety Products PAGE 23 of 40
Registered Company: Thorn Security Ltd. Registered Office: Dunhams Lane Letchworth Garden City Hertfordshire SG6 1BE
EQUIPMENT:
PUBLICATION:
ISSUE No. & DATE:
CAUTION:
THE FINISHING OF A WALK TEST IS ONLY
POSSIBLE IF ALL POINTS IN THE WALK
TEST ARE INACTIVE.
3.13.1.2 SOUNDERS
Select ‘Sounders’ in the Type field.
No results will be shown on the display. The selected
sounders will be activated in a configuration specified
mode.
3.13.1.3 POINT
Select the following settings:
Press F5 to stare the Walk Test.
The following screen shows an example for the Walk Test of
‘Point Input’:
• Area: Point.
• Type: Input (appears automatically).
• Location: Loop (appears automatically).
• Zone Required number.
• Point: Required number.
• Selected 1, if point is in Walk test.
• Excluded 1, if point is not in Walk Test (ie, if
point is isolated).
• Activations: 1, if point was activated during Walk
Test.
• Curr.Active: Yes, if point is currently active.
Point I/P only
Zone 006 A007
Zone 06
Call alarm in room
CP820
Selected : 1
Excluded : 0
Activations : 0
Curr.Active : NO
MX Panel
Wed, 09-Mar-08
00:01
Company Name
General
Back
Walk test
Settings End
TestZ 001
Details
Press F3 for a display of selected settings.
Press F2 for details of the Walk Test (see 3.12.5.1, page 16
for details).
Press F5 to end Walk Test.
CAUTION:
THE FINISHING OF A WALK TEST IS ONLY
POSSIBLE IF ALL POINTS IN THE WALK
TEST ARE INACTIVE.
3.13.2 MAINTENANCE
Press 2 from the Service menu. The following type of
screen will be displayed:
• TestZ Number of zones which are in Walk
Test. (The pointer is only counted if all
points of a zone are in Walk Test. If one
detector on the zone is switched off, the
counter is not decreased. In the case of
Walk Test for one point, the counter is
only decreased if that point is the only
point on the zone).
Total : 000
MX Panel
Wed, 01-Mar-08
14:15
Company Name
General
Back
Maintenance Request
Print
To Next Page
