Page #11 background imageLoading...
Page #11 background image
MX/MZX
17A-04-S
17 10/09
© 2009 Tyco Safety Products PAGE 11 of 40
Registered Company: Thorn Security Ltd. Registered Office: Dunhams Lane Letchworth Garden City Hertfordshire SG6 1BE
EQUIPMENT:
PUBLICATION:
ISSUE No. & DATE:
3.6 MAIN MENU
When the system is in quiescent mode (ie, displaying the
date and time), entering a high level passcode affords the
user access to the main menu. The structure of this menu is
shown below.
Each of the options available leads to further menus or
functions, which are described in the following paragraphs.
3.7 ACCEPT EVENTS
Allows displayed events to be accepted. Press 1 from the
main menu, the following type of screen will be displayed:
Use the F4 Key ‘<<’ and F5 key ‘>>’ keys to move between
events. Usr F3 ‘Accept’ to accept an event.
3.8 VIEW STATUS
Allows the status of all points and zones on the system to be
viewed. Press 2 from the Main menu, the following type of
screen will be displayed:
1 - Accept Events
2 - View Status
3 - Isolate/De-Isol
4 - Time / Date
5 - Event Log
6 - View/Print Data
7 - Service
8 - Configuration
9 - Test Buzzer,
LEDs & Display
Alarm Count: 0021
MX Panel
Thu, 26-Jul-07
00:01
Company Name
General
Back
Main menu
Zone 000 R10
System Zone
Battery Fault IP
BATTERY FAULT
01-Mar-00 14:15:02
Digital Input
SYSTEM
Thu, 26-Jul-07
14:15
Company Name
Fault 02
General
Back
Accept Events
1000
Accept >>
<<
Point Complete - allows the status of all points on the
system (both inputs and outputs) to be checked.
Point Input - allows the status of only input devices to be
checked (eg, detectors).
Point Output - allows the status of only output devices to
be checked (eg, functional bases, sounder etc.).
Zone - allows the total status of all points in a specified zone
to be checked.
Zone Maps - a zone map can be displayed for Alarm, Fault,
Test and Isolated Inputs states. A grid of 80 zones is
displayed which can be scrolled between pages.
Network Status - allows the status of panels on the network
to be checked (only if a network is configured).
Select the required number from the View Status menu, the
following type of screen will be displayed:
Select the type of Point or Zone:
1) Loop Point (Addressable Loop).
2) RBus Point.
3) Local I/O Point.
Point
1 - Loop Point
2 - RBus Point
3 - Local I/O Point
MX Panel
Thu, 26-Jul-07
14:15
Company Name
General
Back
View Status
