Tyco MX Series User Manual

MX/MZX
17A-04-S
17 10/09
© 2009 Tyco Safety Products PAGE 39 of 40
Registered Company: Thorn Security Ltd. Registered Office: Dunhams Lane Letchworth Garden City Hertfordshire SG6 1BE
EQUIPMENT:
PUBLICATION:
ISSUE No. & DATE:
XBUS
RBxxX1 - 40 ZONAL x ALARM
RBxxX41 - 80 ZONAL x FAULT
RBxxX81 SIGNALLING ACTIVE
RBxxX82 SIGNALLING FAULT
RBxxX83 SIGNALLING DISABLED
RBxxX84 PROTECTION EQUIPMENT FAULTY
RBxxX85 SOUNDERS ACTIVE
RBxxX86 SOUNDERS FAULT
RBxxX87 SOUNDERS DISABLED
RBxxX88 PROTECTION EQUIPMENT DISABLED
RBxxX89 PROTECTION EQUIPMENT ACTIVE
RBxxX90 DAY MODE ACTIVE
RBxxX91 MAINS FAULT O/P
RBxxX92 LAMP TEST SPECIAL
RBxxX93 FIRE O/P
RBxxX94 FAULT O/P
RBxxX95 DISABLED O/P
RBxxX96 TEST O/P
xx = MPM800 address
4.3 ADDRESSABLE LOOP
PSEUDO
P01 LOOP FAULT

Tyco MX Series Specifications

General

Type	Fire Alarm Control Panel
Output Voltage	24 VDC
Protection Class	IP30
Networkable	Yes
Operating Temperature	0°C to 49°C
Storage Temperature	-10°C to +60°C
Input Voltage	120/240 VAC, 50/60 Hz
