3.13.3.4 SINGLE DEVICE POLL MODE
When selected, this option allows a single device to be
polled continuously.
Press 6 from the Diagnostics menu, select the Loop and
Point to be polled then press Enter. The following type of
screen will be displayed:
Press F4 to start the device poll, F5 will change to End.
Press F5 to end the device poll.
3.13.3.5 CHANGE ADDRESS
When selected, this option allows the address of a device to
be changed.
Press 7 from the Diagnostics menu. The following type of
screen will be displayed:
Use the ‘>>’, ‘-’ and ‘+’ keys to select the options. Press
Enter when all options have been selected.
CAUTION:
DO NOT SELECT A NEW ADDRESS THAT IS
ALREADY BEING USED ON THE LOOP.
Zone 002 B002
South Building
1st Floor Corridoor
Room 117
801 H
MX Panel
Wed, 01-Mar-00
14:15
Company Name
General
Back
Single Device Poll
Start
MX Panel
Wed, 01-Mar-00
14:15
Company Name
General
Back
Change Address
Loop : B
Old Address : 017
Type : 801H
New Address : 025
New - + Enter
3.13.4 CALIBRATE DDM800
This option is used to calibrate a DDM800 when monitoring
a conventional detection circuit using diode bases.
CAUTION:
THIS OPTION SHOULD ONLY BE USED
UNDER THE FOLLOWING
CIRCUMSTANSES:
1) ON INITIAL COMMISSIONING WHEN THE
CIRCUIT TO BE MONITORED HAS ALL ITS
DETECTORS FITTED.
2) WHEN CHANGES HAVE BEEN MADE TO
DETECTOR TYPES, ADDITIONAL
DETECTORS OR WIRING CHANGES.
Press 4 from the Service Menu, the following screen will be
displayed:
Select the Panel( if networked), Loop and Point address of
the DDM800 to be calibrated, pressing F5 will store the
returned current value for the DDM800.
3.13.5 RESTART SYSTEM
Press 5 from the Service Menu, the following screen will be
displayed:
Pressing 1 will restart the system.
MX Panel
Fri, 01-Aug-08
14:15
Company Name
General
Calibrate DDM800
Panel: 01
Loop: All
Point: All
Back
+
-
Enter
>>
1 - Restart Panel
MX Panel
Thu, 26-Jan-09
00:01
Company Name
General
Back
Restart System

Tyco MX Series Specifications

General

Type	Fire Alarm Control Panel
Output Voltage	24 VDC
Protection Class	IP30
Networkable	Yes
Operating Temperature	0°C to 49°C
Storage Temperature	-10°C to +60°C
Input Voltage	120/240 VAC, 50/60 Hz
