Tyco MX Series User Manual

MX/MZX
17A-04-S
17 10/09
PAGE 3 8 of 40
4. DEFAULT SYSTEM POINTS
4.1 LOCAL I/0 (Field Interface Module/
CPU)
REAL
R01 SOUNDER 1
R02 SOUNDER 2
R03 ALARM RELAY
R04 FAULT RELAY
R04 FIM PSU MONITOR
R06 SUPERVISED INPUT
R07 UNSUPERVISED INPUT
R08 EMERGENCY ALARM I/P
R09 MP EARTH FAULT IP
R10 BATTERY FAULT I/P
R11 MAINS SUPPLY I/P
R12 CHARGER FAULT I/P
R14 I/O 2
R15 I/O 1
R16 24V RESET
PSEUDO
P01 DATA PACKET ERROR
P02 FIFO FULL
P03 EA FIFO FULL
P04 LNET DATA PATH FLT
P05 LNET MODULE FLT
P06 CONFIGURATION STORE
P07 FIM COMMS FAILED
P08 LOOP A FAILED
P09 LOOP B FAILED
P10 LOOP C FAILED
P11 LOOP D FAILED
P12 LOOP E FAILED
P13 LOOP F FAILED
P14 LOOP G FAILED
P15 LOOP H FAILED
P16 BAD PACKET LOCAL I/O
P17 BAD PACKET CHAN A
P18 BAD PACKET CHAN B
P19 BAD PACKET CHAN C
P20 BAD PACKET CHAN D
P21 BAD PACKET CHAN E
P22 BAD PACKET CHAN F
P23 BAD PACKET CHAN G
P24 BAD PACKET CHAN H
P25 FIM BAD PACKET
P26 FIM FAULT
P27 MP ROM FAIL
P28 MP SYSTEM RAM
P29 MP CLOCK
P30 MONITOR POINT
P31 BATTERY LOW
P32 RBUS CIRCUIT FAULT
P33 STACK OVERFLOW
P34 SYSTEM HEAP ERROR
P35 UNSUPERVISED PANEL
P36 RUI CONNECTION
P39 RBUS FIRMWARE
P40 LOCAL I/O F/W
P42 DELAY POOL FULL
P43 WALKTEST SOUNDERS
P44 INHIBIT SOUND LED
P45 COMMISSIONING
P46 DOWNLOAD REQUIRED
P47 TEST EQUIPMENT
P48 WALKTEST OUTPUTS
P54 FORCE DAY MODE
P56 ISOLATION FOR TEST
4.2 RBUS
REAL
RBxxR01 KEY SWITCH
RBxxR06 SILENCE BUZZ BUTTON
RBxxR07 SILENCE/RESOUND BUTTON
RBxxR08 RESET BUTTON
RBxxR09 DAY MODE BUTTON
RBxxR10 INVESTIGATE BUTTON
RBxxR12 EVACUATE BUTTON
RBxxR14 BUZZER
RBxxR15 FAULT LED
RBxxR16 BACKLIGHT INHIBIT
PSEUDO
RBxxR01 MPIM DISPLAY FAIL
RBxxR02 MPIM ROM FAIL
RBxxR03 MPIM RAM FAIL
RBxxR06 BAD PACKET
RBxxR07 MULTICAST SEQ ERR
RBxxR08 CHAR CHIP CSUM ERR

Tyco MX Series Specifications

General

Type	Fire Alarm Control Panel
Output Voltage	24 VDC
Protection Class	IP30
Networkable	Yes
Operating Temperature	0°C to 49°C
Storage Temperature	-10°C to +60°C
Input Voltage	120/240 VAC, 50/60 Hz
