3.13.2.4 VIEW/RESET SOFTWARE
INITIALISATION COUNT
When selected, the number of software initialisations (ie,
operating program restarts) may be viewed/reset.
Press 5 from the Maintenance menu. The following type of
screen will be displayed:
Press F5 to reset the Software Initialisation Count.
3.13.2.5 PROJECT NUMBERS
When selected, this option allows the project and CONSYS
information to be displayed.
Press 6 from the Maintenance menu. The following type of
screen will be displayed:
3.13.2.6 SOFTWARE VERSIONS
When selected, The software versions of the following are
displayed:
• Firmware
• Boot ROM
• Local I/O
• Each Loop
• Each MPM
• Network board
-Firmware 28
MX Panel
Wed, 01-Mar-06
14:15
Company Name
General
Back
Software Init Count
Reset
Project:
Queen El. Hospital
Consys: V1
7.0
Version: 34
Created:
29-Apr-09 10:18
Downloaded:
27-Jun-09 08:20
MX Panel
Wed, 01-Mar-06
00:01
Company Name
General
Back
Project Numbers
Press 7 from the Maintenance menu. The following type of
screen will be displayed:
Press F5 key (+) for additional details of software versions.
3.13.2.7 MENU POINTS
When selected, this option allows any configured point
displayed to be operated by pressing the appropriate number
button, this will toggle from OFF to ON and ON to OFF.
Press 9 from the Maintenance menu. The following type of
screen will be displayed:
3.13.3 DIAGNOSTICS
Press 3 from the Service menu. The following type of
screen will be displayed:
-Firmware V 17.0
-Bootrom V 1.2
-Local I/O V 1.0
-Loop A V 2.1
-Loop B V 2.1
-OCM00 V 2.0
-OCM01 V 2.0
MX Panel
Thu, 26-Jul-07
14:15
Company Name
General
Back
Software Versions
+
Print
MX Panel
Wed, 01-Mar-08
14:15
Company Name
General
Back
Menu Points
>>
Menu Point 1: OFF
Isolate Zone
Menu Point 2: ON
Sensit.Change
Menu Point 3:
-Unconfigured-
Menu Point 4:
-Unconfigured-
ON
1 - Force Dev.O/P
2 - Force Dev.I/P
3 - Shutdown/Rstart
6 - Single. dev.poll
7 - Change Address
MX Panel
Wed, 01-Mar-00
14:15
Company Name
General
Back
Diagnostics
Commissioning
