Tyco MX Series User Manual

MX/MZX
17A-04-S
17 10/09
© 2009 Tyco Safety Products PAGE 17 of 40
Registered Company: Thorn Security Ltd. Registered Office: Dunhams Lane Letchworth Garden City Hertfordshire SG6 1BE
EQUIPMENT:
PUBLICATION:
ISSUE No. & DATE:
3.12.1 VIEW/PRINT POINTS ISOLATED
Select option 1 from the View/Print Status menu, the
following type of screen will be displayed:
Note: If the panel is part of a networked system,
another screen is displayed before the above
screen where the panel number may be
selected.
Press F5 ‘Print’ to print a list of all isolated points.
The F2 Key selects either isolated inputs or isolated outputs.
Points which are completely isolated (input and output) will
be shown in both lists.
3.12.2 VIEW/PRINT POINTS UNTESTED/
FAILED
Note: Note this option only works whilst still in
Walktest.
Select option 2 from the View/Print Status menu, the
following type of screen will be displayed:
Note: If the panel is part of a networked system,
another screen is displayed before the above
screen where the panel number may be
selected.
Press F5 to print the Untested/Failed points.
Points which are not tested or points which return the wrong
condition are then listed.
Input
Total : 004
Zone 001 -001 B
Point Text
--------------------
001 -002 B
Point Text
MX Panel
Thu, 26-Jul-07
14:15
Company Name
General
Back
Points Isolated
Print
Output
Total : 004
Zone 001 -001 B
Point Text
--------------------
Zone 001 -002 B
Point Text
MX Panel
Thu, 26-Jul-07
14:15
Company Name
General
Back
Pts Untested/Failed
Print
3.12.3 VIEW/PRINT POINT VALUES
Select option 3 from the View/Print Status menu, the
following type of screen will be displayed:
Select the panel number (if the panel is part of a networked
system), loop and point number required.
After pressing Enter, the following type of screen will be
displayed:
Press F5 to print Point Values, values for all devices on the
loop will be printed.
3.12.4 VIEW FAULTS
Select option 4 from the View/Print Status menu, the
following type of screen will be displayed:
Press F5 to print.
Panel 02
Loop Point
A 002
MX Panel
Thu, 26-Jul-07
14:15
Company Name
General
Back
Point Values
Enter
>> - +
Zone 003 A023
Zone 03
Heat Sensor Device
801 H
Real: 801H
Mode: Std R.o.(21)
Sens: N/A
22 C (073)
MX Panel
Wed, 01-Jan-09
14:15
Company Name
General
Back
Point Values
Print
o
Total : 002
Zone 000 R10
Zone 000 R12
MX Panel
Thu, 26-Jul-07
14:15
Company Name
Flt P 002
General
Back
View Faults
Print

Tyco MX Series Specifications

General

Type	Fire Alarm Control Panel
Output Voltage	24 VDC
Protection Class	IP30
Networkable	Yes
Operating Temperature	0°C to 49°C
Storage Temperature	-10°C to +60°C
Input Voltage	120/240 VAC, 50/60 Hz
