Press 3 from the Main menu. The following screen will be
displayed:
Select the required number from the Isolate/De-Isolate
menu or from the soft keys, then select the type of point (as
described in Section 3.7):
• Loop Point (Addressable Loop)
Use the ‘+’, ‘-’ and ‘>>’ keys to select the
required Loop and Point, then press Enter
key.
• RBus Point (Remote Bus)
Use the ‘+’, ‘-’ and ‘>>’ keys to select the
required RBus, Category and Point, then
press Enter key.
• Local I/O Point (Field Interface Module)
Use the ‘+’, ‘-’ and ‘>>’ keys to select the
required Category and Point, then press
Enter key.
The following screen shows an example Point isolation:
In the ‘Customer Operator’ access levels, only points on the
addressable loop can be isolated or de-isolated.
Isolations are counted and displayed (eg, Isol 001). If only
the input or output of a point is isolated, this is counted as a
complete isolation of the point.
1 - Point
2 - Point I/P only
3 - Point O/P only
4 - By Function
9 - Non-LED Outputs
Zones 000 A.I/P 000
Sndrs 000
MX Panel
Wed, 01-May-09
14:15
Company Name
General
Back
Isolate/De-Isolate
Alm Sig All SNDFlt Sig
Ext.Ctl
Point Complete
Zone 002 B002
South Building
1st Floor Corridoor
Room 117
801 H
Status IP: Normal
ISOLATED INPUT
2 - De-Isolate
MX Panel
Wed, 01-Mar-08
14:15
Company Name
Isola 001
General
Back
Isolate/De-Isolate
Isolation Status
The following screen shows an example detector isolation:
Successes: Number of points that were
(De-)Isolated
Matches: Number of detectors in zone
The following screen shows an example of All Sounders
isolation:
Successes: Number of sounders (De-)Isolated
Matches: Number of sounders in all Zones
Isola: Number of isolated points
Iso.S: Number of isolated sounders
Press 9 from the main menu ‘Non-LED Outputs’, after
selecting ‘Isolate’, the following screen will be displayed:
All log and LED outputs are as configured but loop and FIM
outputs are not switched.
Detectors
Zone 001
Zone 01
Isolate
All
Successes : 003
Matches : 003
MX Panel
Wed, 01-Mar-09
14:15
Company Name
Isola 003
General
Back
Isolate/De-Isolate
All Sounders
Successes : 006
Matches : 006
MX Panel
Wed, 01-Mar-00
14:15
Company Name
Isola 006
Iso.S 006
General
Back
Isolate/De-Isolate
Non-LED Outputs
Points ISOLATED
Timeout: 00:59:58
Success :0020
Matches :0020
MX Panel
Wed, 01-May-09
14:15
Company Name
General
Back
Isolate/De-Isolate
Isola 020
Iso.S 004

Tyco MX Series Specifications

General

Type	Fire Alarm Control Panel
Output Voltage	24 VDC
Protection Class	IP30
Networkable	Yes
Operating Temperature	0°C to 49°C
Storage Temperature	-10°C to +60°C
Input Voltage	120/240 VAC, 50/60 Hz
