58.4 mm(2.299 in)Total brake thickness
36 ±0.1 mm(1.417 in)Metal brake assembly
Installed thickness
2 on each sideNumber of plates
2.5±0.09 mm(0.098 in)Thickness
Φ188mm(Φ7.4 in)Outer diameter
Separator
Plate
4 on each sideNumber of plates
Paper baseLining material
3.4±0.1 mm(0.134 in)Thickness
Φ184mm(Φ7.24 in)Outer diameter
Wet,multi-disc,Mechanically operatedTypeFriction
Plate
Brake system
5.5Reduction ratio
Helical gearsType
Final reduction gears
3510/4110/T390(T400)/T430(T450)MODEL
SECTION 2. SPECIFICATIONS
7-2
