Tynetec Advent XT2 - Table of Contents

Doc No. FM0804 issue 4 Page 2
CONTENTS
Section
Topic
Page
1
Introduction
3
2
Safety Instructions
4
3
Regulatory Information
5
4
Maintenance & Care
5
5
Related Documentation
6
6
System Options
7
7
Controller Installation
9
8
Network Wiring
12
9
Network Load Considerations
13
10
Network Termination Board
14
11
Network Cable Colour Code
17
12
PA Amplifier Installation
18
13
External Battery Box Installation
20
14
Intercom Unit Installation
21
15
Intercom Unit DIL Switches & Link Settings
23
16
Intercom Unit Auxiliary Devices
24
17
Fitting & Removing the Intercom
28
18
Intercom Unit Test Mode
29
19
Manager Callpoint Installation
30
20
Lift Callpoint Installation
31
21
Manager’s Display Panel Installation
32
22
Network Receiver Installation
38
23
Door Entry Panel Installation
40
24
Door Entry Telephone Installation
43
25
Door Open Alarm Installation
45
26
Line Selector Installation
46
27
Data Repeater Installation
47
28
Specification - Controller
48
29
Specification - PA Amplifier
49
30
Specification - External Battery Box
50
31
Specification - Intercom
51
32
Specification - Intercom I/O Expander
52
33
Specification - Manager Callpoint
53
34
Specification - Lift Callpoint (Flush Stainless Steel)
54
35
Specification - Lift Callpoint (Surface ABS)
55
36
Specification - 869MHz Network Receiver
56
37
Specification - Manager’s Display Panel
57
38
Specification - Door Entry Panel
58
39
Specification - Door Entry Telephone
59
40
Specification - Line Selector
60
41
Specification - Data Repeater
60
42
Specification - Door Open Alarm
61
43
Specification - Master Strobe
62
44
Specification - Slave Strobe
62
45
Amendments Record
63
