Tynetec Advent XT2 - Specification - Intercom I;O Expander

Doc No. FM0804 issue 4 Page 52
32. SPECIFICATION - INTERCOM I/O EXPANDER
Tynetec Part No’s
ZXT925
EMC Approval
EN 55022
Safety Approval
EN 60950
Data Connection
RS485 (19200 Baud)
Power Requirement
24V DC @ 2mA (standby)
4 Way DIL Switch
No Function
Features
Inputs
6 x Programmable N/O Inputs (switched 0V)
Outputs
6 x Programmable C/O Relay Outputs (contacts rated 30V DC @ 1A)
Mechanical
Enclosure Material
Light Grey ABS (RAL 7035)
Flammability Rating
UL 94 V-0
Ingress Protection Rating
IP54
Dimensions
170mm x 85mm x 34mm (LxWxD)
Weight
235 grams
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
