Tynetec Advent XT2 - Specification - Line Selector; Specification - Data Repeater

Doc No. FM0804 issue 4 Page 60
40. SPECIFICATION - LINE SELECTOR
Tynetec Part No.
ZXT330
EMC Approval
N/A
Safety Approval
N/A
Features
Power Requirement
12V DC @ 40mA active (0mA standby)
BT47 Relay
Fully sealed DPDT contacts rated 2A @ 30V DC
Telecom Connectors
3 x BT Type 431A Sockets
Screw Terminals
12V & 0V Enable
Telecom Leads (2 No.)
1 metre long 6 core FCC68 flat cable with BT Type 431A Plugs
Mechanical
Enclosure Material
Light Grey ABS (RAL 7035)
Flammability Rating
UL 94 V-0
Ingress Protection Rating
IP54
Dimensions
170mm x 85mm x 34mm (LxWxD)
Weight
178 grams
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
41. SPECIFICATION - DATA REPEATER
Tynetec Part No.
ZXT340
EMC Approval
N/A
Safety Approval
N/A
Features
Power Requirement
24V DC @ 10mA (standby)
Links LK1-LK4
Link selectable pull-up/pull-down resistors on RS485 IN/OUT terminals
4 DIL Switch SW1
Switchable end of line resistors on RS485 IN terminals
4 DIL Switch SW2
Switchable end of line resistors on RS485 OUT terminals
RS485 IN LED Indicators
LED1: Yellow RX, LED2: Red TX
RS485 OUT LED Indicators
LED3: Yellow RX, LED4: Red TX
Mechanical
Enclosure Material
Light Grey ABS (RAL 7035)
Flammability Rating
UL 94 V-0
Ingress Protection Rating
IP54
Dimensions
170mm x 85mm x 34mm (LxWxD)
Weight
202 grams
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
