Tynetec Advent XT2 - Specification - Master Strobe; Specification - Slave Strobe

Doc No. FM0804 issue 4 Page 62
43. SPECIFICATION - MASTER STROBE
Tynetec Part No.
ZSL060 (Blue) & ZSL065 (Clear)
EMC Approval
N/A
Safety Approval
N/A
Features
Power Requirement
24V DC @ 2mA (standby) 90mA active
Data Connection
RS485 (19200 Baud)
Max No. Strobes
4 per combined intercom (2 warden call + 2 door entry)
Strobe Lamp
Xenon
Strobe Flash Rate
100 per minute
Strobe Power Output
1 Watt
Strobe Flash Duration
20 Seconds
DIL Switch 1
OFF: flash on warden call, ON: flash on door entry
DIL Switch 2
OFF: primary strobe, ON: secondary strobe
DIL Switch 3
No Function
DIL Switch 3
No Function
Mechanical
Enclosure Material
Off White ABS (RAL 9002)
Flammability Rating
UL 94 HB
Ingress Protection Rating
IP40
Dimensions
110mm diameter x 57mm deep
Weight
135 grams
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
44. SPECIFICATION - SLAVE STROBE
Tynetec Part No.
ZSL047 (Clear)
EMC Approval
N/A
Safety Approval
N/A
Features
Power Requirement
12V DC @ 0mA (standby) 160mA active
Max No. Strobes
2 per door entry telephone
Strobe Lamp
Xenon
Strobe Flash Rate
100 per minute
Strobe Power Output
1 Watt
Strobe Flash Duration
20 Seconds
Mechanical
Enclosure Material
Off White ABS (RAL 9002)
Flammability Rating
UL 94 HB
Ingress Protection Rating
IP40
Dimensions
110mm diameter x 57mm deep
Weight
115 grams
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
