Tynetec Advent XT2 - Specification - External Battery Box

Doc No. FM0804 issue 4 Page 50
30. SPECIFICATION - EXTERNAL BATTERY BOX
Tynetec Part No.
ZXT902
EMC Approval
EN 55022
Safety Approval
EN 60950
Features
Rechargeable Battery Type
2 x 12V 5Ah Sealed Lead Acid (Tynetec P/No. F00050)
Battery Standby Time
12 Hours (based on 5 calls/hour on a typical 40 way system)
Battery Leads
1.3m x 24/0.2 PVC insulated wire (BS 4808 Part 2)
Crimp Adapter Type
2 Way Tab to Receptacle 4.8mm x 0.8mm (TE Connectivity 63699-1)
Fuse Type
20mm 3.15A S/B
Mechanical
Enclosure
Polyester Powder Coated 18 SWG Mild Steel (RAL7035)
Mounting
Wall Mount
Ingress Protection Rating
IP40
Dimensions
230mm x 185mm x 80mm (HxWxD)
Weight
4.8kg
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
20% to 90% RH
Relative Humidity
Non-condensing
