Tynetec Advent XT2 - Specification - Door Entry Panel

Doc No. FM0804 issue 4 Page 58
38. SPECIFICATION - DOOR ENTRY PANEL
Tynetec Part No’s
ZXT950 Standard, ZXT951 with Emergency Button (AHA Only)
EMC Approval
EN 55022
Safety Approval
EN 60950
Data Connection
RS485 (19200 Baud)
Power Requirement
24V DC @ 30mA (standby)
Audio Channels
2 Handsfree Voice Switched with Digital Volume Control
8 Way DIL Switch
1 to 4 = Set Binary ID, 5 = Voice Synthesis Enable, 6/7/8 Not Used
2 Jumpers
LK1 = Lock Type & LK2 = System Type (A = XT2, B = Entel)
Loudspeaker
Mylar Cone 8 Ohm 2 Watts
LED Indicators
LED1: Yellow Data RX, LED2: Red Data TX
Features
Flush Mount
Standard
Surface Mount
Optional HM1140 Surface Cowling required
Rain Hood
Optional HM1105 Flush Cowling required
Pushbuttons
20mm Diameter Stainless Steel
Loudspeaker
Protected by Fine Mesh Stainless Steel Grill
Microphone
Protected by Fine Mesh Stainless Steel Grill
DDA Compliance
High Visibility Yellow Halo around Pushbuttons, Pip on No. 5
Speech Messages
Yes (can be disabled on DIL switch 5)
Display
2 Line x 16 Character Backlit LCD (8mm High Characters)
Display Contrast
Adjustable
Display Window
5mm Clear Makralon Polycarbonate
Panel Mount Reader Option
Yes - standard 40mm square cut-out with 4 studs on 48.5mm centres
Lock Output
Relay Contacts rated 30V DC @ 1A
Lock Type Options
LK1A = Fail Secure, LK1B = Fail Secure
Lock Fuse
20mm 1A
Lock Release Time
Adjustable 1 to 255 Seconds (default 10 Secs)
Telephone Ring Cycles
Adjustable 1 to 99 (default 8 Cycles)
Speech Time
Adjustable 1 to 255 Seconds (default 60 Secs)
Access Codes
4 Programmable 4 Digit Access Codes
Trade Times
3 Programmable Trade Time Periods Per Day
Tailgate Input
N/C Door Contact required
External Lock Input
N/O Press to Exit Button required
Fixings
6 No. M5 x 12mm Countersunk Allen Head Bolts
Fixing Tool
3mm Allen Key
Mechanical
Fascia Material
12 SWG Stainless Steel
Fascia Dimensions
406mm x 160mm x 2.64mm (HxWxD)
Bezel Material
18 SWG Stainless Steel
Bezel Dimensions
14mm Wide
Backbox Material
16 SWG Galvanized Mild Steel
Backbox Dimensions
406mm x 160mm x 60mm (HxWxD)
Ingress Protection Rating
IP44
Weight
3.60 kilograms (inc Backbox)
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
