36. SPECIFICATION - 869MHz NETWORK RECEIVER
Tynetec Part No.
ZXT910
EMC Approval
EN 55022
Safety Approval
EN 60950
Radio Approval
R&TTE 1999/5/EC
Radio Frequency
869.2125MHz
Radio Range
75 metres typical (indoor)
Max No. TCR’s per Site
32
Data Connection
RS485 (19200 Baud)
Power Requirement
24V DC @ 6mA (standby)
Antenna
869MHz SMA Dipole Antenna (195mm long)
Antenna Connection
SMA-RP Gold Female Bulk Head with 5cm 1.13mm diameter U.FL
8 Way DIL Switch
1 to 5 = Binary ID, 6&7 Not Used, 8 = Protocol (OFF = TSP, ON = XT2)
LED Indicators
LED1: Green RF RX, LED2: Yellow RS485 RX, LED3: Red RS485 TX
Mechanical
Enclosure Material
Light Grey ABS (RAL 7035)
Flammability Rating
UL 94 V-0
Ingress Protection Rating
IP60
Dimensions
120mm x 80mm x 55mm (LxWxD)
Weight
222 grams (inc Antenna)
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
