Tynetec Advent XT2 - Specification - Managers Display Panel

Doc No. FM0804 issue 4 Page 57
37. SPECIFICATION - MANAGER’S DISPLAY PANEL
Manager’s Display Panel
Manufacturer/Model No.
Avalue Technology Inc. CCD-10W01-7838C-1R
Tynetec Part No.
ZXT905
EMC Approval
FCC Part 15 Class B Digital Device
Safety Approval
EN 60950-1
Radio Approval
R&TTE 1999/5/EC
Display
Size
10.1”
Type
SXGA (Super Extended Graphics Array)
Resolution
1280 x 800 pixels
Luminance
350 Cd/m2
Viewing Angle
170
o
(H/V)
Backlight
LED
Touch Type
PCAP (Projective Capacitive)
System
Processor
Intel Atom Z3735F 1.33GHz
Memory
2GB DDR3L RAM
Storage
32GB eMMC
Operating System
Windows 10 IoT 32 Bit
I/O
USB
2 x USB 2.0
HDMI
1 x HDMI
LAN/Ethernet
1 x RJ45 (10/100 Base-Tx GbE compatible)
WiFi
IEEE 802.11 b/g/n
Audio/Video
Speaker Output
2 x 2 Watt Stereo
Audio Interface
Line-Out
Camera
2 MP
Power Supply
Manufacturer/Model No.
Delta Electronics Inc. ADP-40KD-BB
Input
100-240V AC 1.2A 50/60Hz
Output
19VDC @ 2.1A (40W)
Efficiency
85%
Protection
Overload/Over Voltage/Short Circuit (auto shut-down/recovery)
Dimensions
89.5mm x 37mm x 26.5mm (LxWxD)
Weight
290 grams (inc mains lead and UK plug)
Low Voltage Lead
1.8m x UL1571 22AWG with R/A DC Jack (5.5mm OD x 2.5mm ID)
Mains Lead
0.8m x H05VV-F 0.75mm 3 core with UK 13A Plug (1” 5A fuse)
Mechanical
Enclosure
White ABS
Mounting
VESA 75 (75mm x 75mm centres) – wall mounting bracket supplied
VESA Bracket Fixings
4 No. M4 x 6mm pan head screws supplied
Dimensions
261mm x 175mm x 34mm (WxHxD)
Weight
625 grams (excluding VESA bracket & PSU)
Environmental
Operating Temperature
5
o
C to 40
o
C
Storage Temperature
-20
o
C to 60
o
C
Operating Humidity
0% to 90% RH
Relative Humidity
Non-condensing
