6. SYSTEM OPTIONS
Part No.
Description
Notes
ZXT900
Advent XT2 Controller
includes power supply & standby batteries
ZXT901
Advent XT2 PA Amplifier
maximum 80 PA intercoms per PA Amplifier
ZXT902
Advent XT2 External Battery Box
optional for XT2 Controller (24 hour battery standby)
ZXT905
Manager’s Display Panel
maximum 32 per system
W07485
5 Port Ethernet Switch
for up to 4 Manager’s Panels (larger switches available)
ZXT920
Standard Intercom + PA
255 network nodes as standard, this can be increased to 512 if
the second RS485 databus is connected.
Intercoms, callpoints, network receivers and door panels are
all network nodes.
Intercoms can connect ceiling pullcords, smoke detectors, PIR
detectors and up to 4 additional programmable inputs as
standard.
ZXT930
Door Entry Intercom + PA
ZXT931
Door Entry Intercom + PA + Bluetooth
ZXT940
Manager Callpoint
ZXT941
Custom Engraved Callpoint
ZXT942
Lift Callpoint (Flush S/S)
ZXT943
Custom Engraved Lift Callpoint (Flush S/S)
ZXT944
Lift Callpoint (Surface ABS)
ZXT925
Intercom I/O Expander
1 per intercom for additional 6 inputs + 6 outputs
ZXT935
Bluetooth Remote Control
optional for use with ZXT931 door entry intercom
S00600
Ceiling Pullcord with 24V LED Reassurance
Use normally open contacts - maximum 5 per intercom with
LED connected (no limit without LED)
N/A
Smoke Detector
use mains powered smoke detectors with integral
rechargeable standby battery & normally open relay output
N/A
PIR Movement Detector
use 12V DC PIR’s with normally closed relay output (a 24V-12V
regulator board will be required in each intercom)
A00557
24V-12V Regulator Board
1 per intercom for PIR 12V supply
ZXT910
869MHz Network Receiver inc Antenna
maximum 32 per system
ZXT8xx
869MHz Telecare Devices
maximum 8192 per system
ZXT950
Digital Door Panel + Manager Button
maximum 16 per system
W00525
12V/2A Power Supply Unit
1 per door panel (for lock supply)
ZXT955
Door Entry Telephone
maximum 2 per intercom (master & extension)
REMOTE CONTROL CENTRE (PSTN ARC)
The PSTN alarm receiving centre must support BS8521 or TT92 protocol. The Advent XT2 can have 2 dedicated PSTN
telephone lines connected, this will allow 2 simultaneous offsite calls or if one line fails the second line will
automatically be selected.
DIGITAL COMMUNICATOR (IP ARC)
The ARC must support Now IP protocol. A Broadband connection with a fixed IP address is required.
MANAGER’S DISPLAY PANEL
A maximum of 32 Manager’s display panels can be connected on the Advent XT2 system. These are wall mounted
10.1” TFT touch screen monitors to display call information and the system status, they are also used to setup system
features and to add/remove radio devices. A large screen “Notice Board” monitor can be connected to the HDMI port
of each Manager’s panel to display information on events or messages for staff/residents. Manager’s panels require a
local mains supply and connection to the Advent XT2 controller via an Ethernet switch.
NETWORK RECEIVERS & TELECARE DEVICES
A maximum of 32 x 869MHz network receivers can be connected on the Advent XT2 system. Up to 8192 x 869MHz
Telecare radio devices can be registered per site (16 per dwelling). Radio devices include; personal pendants, fall
detectors, flood detectors, temperature sensors, gas detectors, CO detectors, etc.
DOOR ENTRY OPTION
Up to 16 digital door entry panels can be connected on the Advent XT2 system - additional PSU’s will be required for
door locks. Door panels have a “Manager” button as standard, door entry telephone or intercom options are available.
PA OPTION
A public address (PA) option is available to broadcast general announcements or a fire alarm tone through all
intercoms. All intercoms have a PA facility as standard, one PA amplifier is required for every 80 intercoms. Each group
of 80 intercoms must be wired on a separate network leg.
