Controls
7
7.01
Controls
On/off switch
2
1
77-005
Fig. 7 - 01
Fig. 7 - 01a
Machines with Typical-EcoDrive
● The power supply to the machine is swit-
ched on or off by turning switch 1.
Machines with Typical-PicoDrive
● Operate main switch 2 to switch the
machine on or off.
7.02
Keys on the machine head (only for machines with -911/..)
● As long as key 1 is pressed during sew-
ing, the machine sews in reverse.
2
● Keys 2 can be used for parameter set-
tings (see parameter 446 and 748 in the
instruction manual for the motor).
1
Fig. 7 - 02
15
