typical TW1-571 - Bobbin Thread Monitoring with Stitch Counting (Only with Ecodrive); Pedal

Controls
7.03
Bobbin thread monitoring with stitch counting (only on machines with EcoDrive)
● After the pre-set number of stitches have
been sewn, diode 1 flashes.
● After the thread has been trimmed and
the bobbin changed, the stitch counting
begins anew.
Presetting the number of
stitches (see description in
the instruction manual for the
motor.
1
Fig. 7 - 03
7.04
Pedal
0 =
+1 =
-1 =
Neutral position
Sewing
Raise roller presser (on
machines with -910/..)
Trim sewing threads (on
machines with -900/..)
0
-2 =
+1
-1
-2
Fig. 7 - 04
16
