typical TW1-571 - Setting the Stitch Length; Adjusting the Stitch Counter for the Bobbin Thread Control

Setting up
9.07
Setting the stitch length
2
3
61-01661-016
1
Fig. 9 - 07
● Press key 1 and at the same time turn the balance wheel until the stitch setter clicks into
position.
● Hold down key 1 and turn the balance wheel to and fro until the stitch length required is
shown on the scale 2 opposite the bottom edge 3 of the belt guard recess.
9.08
Adjusting the stitch counter for the bobbin thread control (only on machines
(only on machines with Typical Motor and P40 (ED) control unit)
Please see the description in the separate control panel instruction manual.
werden.
36
