Care and maintenance
10.06
Filling the oil reservoir of the thread lubrication unit
Check the oil level before each
use.
There must always be oil in re-
servoir 1.
● If required refill oil through hole.
We recommend
TYPICAL thread lubricating oil,
Order No. 280-1-120 217.
1
Fig. 10 - 05
10.07
Parameter settings
(only on machines with Typical-EcoDrive and control unit P40ED or Typical-PicoDrive and
control unit P44 PD-L )
● The selection of the user level and the alteration of parameters is described in the sepa-
rate instruction manual for the drive unit.
10.07.01
Parameter list
700
700
0
0
1
105
110
Speed for start backtackl
Speed for end backtack
Bartacks
(1 = ornamental bartack, 0 = standard
bartack)
Speed display
B, C
B, C
A, B,
C
B, C
300 - 2000
300 - 2000
0-1
700
700
0
5
523
6
L
605
0-1
See Chapter 3 Specifications
Adjustment see Chapter 8.09 Basic position of the machine drive unit.
*
40
0
Parameter
Group
Description
Userlever
Setting Range
Set value P40 ED
Set value P44 PD-L
