114
Table 3.2.
Seats
Weight group
Front
passenger’s seat
Rear side seat Rear center seat
0–10 kg
(0–9 months)
X* U* X
0+ – 13 kg
(0–2 years)
X U X
I — 9–18 kg
(9 months – 4 years)
U U X
II and III — 15–36 kg
(4–12 years)
U U X
* Child seat category
U — universal category of a child seat suitable for settling a child
both into a front-facing seat and a rear-facing seat.
X — child seats mounting is not permitted.
Fuel tank plug
To access the fuel tank plug (for UAZ PATRIOT, UAZ PICKUP
vehicles) open the ap (Fig. 3.38). On UAZ CARGO vehicle, the
fuel tank plug is under the cargo bed, right front in open access.
ATTENTION! Fuel tank hatch cover has an opening angle
restriction of 70°. Opening the cover to a larger angle will cause
a deformation of the hinge movable link, and when closing the
cover of the fuel ller door, the hinge will not butt up against the
door bumper.
