115
Hood
In order to open the hood, pull lever 10 (see Figs. 3.1, 3.2)
between the hood and the radiator lining, push the clamp of hook
1 (Fig. 3.39) and lift the hood. Take out hood latch 3 from holder
2 by pushing it and insert it into a special opening above the right
headlight. Depending on the conguration, the motor vehicle may
be equipped with air springs for the hood, which facilitate lifting
of the hood and maintain it open.
The hood closing must be performed from a height not more
than 200 mm above the radiator lining. If the motor vehicle is
equipped with air springs for the hood, the latter should close by
inertia after overcoming the force of the air springs.
Fig. 3.26. Fuel ller ap
and choke plug
Fig. 3.39. Hood: 1 — locking hook; 2 — support; 3 — rest
