UAZ PICKUP - Airbags

108
Diagnostics of defective unfastened
seatbelt indicator
Seatbelt signal device
is on when the driver’s seatbelt is
fastened. Disconnect the receptacle of the retractable seatbelt
buckle:
– the signal device goes of, if the retractable seatbelt buckle is
defective;
– the signal device remains illuminated, if the wiring harness
or the instrument cluster is defective.
Airbags
Motor vehicle is equipped with front airbags system for the
driver and the front passenger, front seatbelts with pretensioners
and the load limiter. When the airbags system actuates, the front
seatbelts are retracted within a short period of time for secure xa-
tion of the driver and the passenger and the air bags are lled with
gas, and unfolding in front of the driver and the front passenger,
reduce the danger of head and upper body part injuring. Airbags
system actuates at frontal collision of motor vehicle, when it is
needed to increase the safety of the driver and the front passen-
ger. The presence of airbags system is marked by the inscription
“AIRBAG” on the steering wheel cover, inscription “AIRBAG”
on the dashboard cover and inscription “AIRBAG” on the seatbelt
strap label.
Airbags system includes:
– driver airbag module built into the steering wheel;
– airbag module located in the dashboard above the glove
compartment;
– front seatbelts with load limiter;
– driver seatbelt condition sensor;
– front seatbelts locks with pretensioner;
– rotating device mounted on the understeering switch con-
nector (for connecting of the horn switch-off and airbag module
to the vehicle circuit board);
