7
TECHNICAL SPECIFICATIONS
* Dimensions are averaged, given for reference and can vary depending on operation conditions, installed tires, their condition and tire pressure, motor vehicle
load, suspension condition, etc.
** Motor vehicle UAZ-236321 with cargo compartment and a wing rear door belong to N1G vehicle category
Name
UAZ Patriot UAZ Pickup UAZ Cargo
UAZ-3163/UAZ-236321** UAZ-23632 UAZ-23602 (01/02)
1 2 3 4
General data
Motor vehicle type All-terrain, two-axle, 4WD axle conguration
Vehicle dimensions * Shown in Fig. 1.5-1.11
Maximum bearing capacity
(including driver and passengers), kg
600 800 800 (665/575)
Seating capacity (including driver’s seat) 5 5 2
Maximum gross
vehicle weight, kg 2,650/2,670 2,860 2,775
Gross weight distribution by axles, kg:
on the front axle
on the rear axle
1,217/1,114
1,433/1,556
1,230
1,630
1,090 (1,145/1,132)
1,685 (1,630/1,643)
Vehicle curb weight
(including driver), kg 2,125 2,135 2,050 (2,185/2,275)
Curb weight distribution by axles, kg:
on the front axle
on the rear axle
1,150
975
1,150
985
1,120 (1,096/1,097)
930 (1,089/1,178)
