21
1 2 3 4
Gap between spark plugs electrodes, mm 0.7
+0,15
Brake pedal free play, mm 5–8
Front wheel toe-in 0°4'–0°10'
Largest turning angle front inner wheel,
deg. 31–32
Steering system total play (steering wheel
angle from the position corresponding to
the beginning of steerable wheels turning
in one direction to the steering wheel
position corresponding to the beginning
of steerable wheels turning in the opposite
direction), deg., max. 20
Wheel and tire in assembly unbalance,
g∙cm, max. 1000
Tire air pressure,
MPa (kgf/cm
2
):
in the front wheels:
225/75R16
235/70R16
245/70R16
245/60R18
0.20 (2.0)
0.19 (1.9)
0.17 (1.7)
0.18 (1.8)
0.20 (2.0)
0.19 (1.9)
0.17 (1.7)
–
0.19 (1.9)
–
–
–
