49
– when the signal device switches on in the cluster, release
the switch handle (the switch handle self-resets to the ‘4L’ position);
– start driving, smoothly releasing the clutch pedal.
Driving mode change 4L=>4H
To switch on the mode of all-wheel drive with underdrive it is
necessary to:
– stop the motor vehicle;
– press and hold the clutch pedal;
– set the switch handle from the ‘4L’ position to the ‘4H’ position;
– when the signal device
switches on in the cluster, start
driving, having smoothly released the clutch pedal.
2+ — preheater starting switch
.
3+ — rear wheel differential lock switch
.
To switch the lock on press and hold button 3 (Fig. 3.11) until
the rear axle differential lock signal device turns on
in the
cluster. On motor vehicles UAZ PATRIOT and UAZ PICKUP
(with transfer box ‘Dymos’) preliminary shift the transfer box
in 4L mode, on motor vehicles UAZ CARGO (with transfer box
‘UAZ’) — in 4x4 mode. After the lock is on ABS is automati-
cally turns off, as a result ABS malfunction signal device lights
up (Fig. 3.5), LED-display of the cluster shows the following
messages: ‘Wheel differential lock is off’, ‘Hill start assistance is
off’, ‘ABS is off’. Manual switching off of the lock is possible at
any time by repeated pushing and holding of button 3 (Fig. 3.11)
until the rear axle differential lock signal device is turned off .
Besides, the lock is turned off automatically after the key is
removed or if the speed exceeds 30 km/h, and on motor vehicles
UAZ PATRIOT and UAZ PICKUP (with transfer box ‘Dymos’)
also when mode 4L is off. After the lock is turned off signal devices
go off in the cluster too (Fig. 3.5).
