7.LADDER DIAGRAM
94
Address Map for the Sample Ladder Diagram
Address Data Type Comment Note
100.00 BOOL Final data write start
Used for sequece control
of sample ladder
100.01 BOOL Final data set
100.02 BOOL Wait for a write
100.03 BOOL Write complete
100.04 BOOL Start to read
100.05 BOOL Wait for a read
100.06 BOOL Read complete
100.07 BOOL Start comparison
100.08 BOOL Comparison complete
200.13 BOOL Final setting error For read/write error detection
2001.12 BOOL Request
F159 relay area2001.14 BOOL R/W
2009.12 BOOL Request
D113 CHANNEL
Final write data
(lower 4 digits)
Write data
D213 CHANNEL
Final read data
(lower 4 digits)
Read data
D300 CHANNEL Wait for write complete
Used as a wait time counter
D301 CHANNEL Wait for read complete
D20000
D20051
CHANNEL
DM area for allocating F159’s
weighing settings and initial setting
data
To Next Page
