Unipulse F331 - List of Setting Values; Comparison Setting; Operation Setting; Calibration Setting

12
3 SETTING METHOD
12
SETTING METHOD
Chapter
3
3-3. List of setting values
■Comparison setting
■Operation setting
■Calibration setting
Item Initial value Setting range Page
HH limit +9999 -9999 to +9999 P. 16
HI limit +0750 -9999 to +9999 P. 16
LO limit +0250 -9999 to +9999 P. 16
LL limit -9999 -9999 to +9999 P. 16
Hysteresis 0000 0000 to 9999 P. 17
Digital offset 0000 -9999 to +9999 P. 18
Near zero 0000 0000 to 9999 P. 18
Comparison timing 0: Always
0: Always, 1: NZ,
2: Hold/Judge, 3: NZ+Hold/Judge
P. 18
Item Initial value Setting range Page
Moving average filter 1 1 to 512 [times] P. 18
Digital low-pass filter 2: 12 0: 3, 1: 6, 2: 12 [Hz] P. 18
Hold mode 0: OFF
0: OFF, 1: Sample, 2: Peak,
3: Valley, 4: P-P
P. 19
ZERO key valid/invalid 0: Valid 0: Valid, 1: Invalid P. 21
Display frequency 2: 20 0: 5, 1: 10, 2: 20 [times/sec.] P. 21
External
output selection
Output selection 1 3: HI 0: OK, 1: NG, 2: HH, 3: HI, 4: LO, 5: LL
P. 23
Output selection 2 4: LO 0: OK, 1: NG, 2: HH, 3: HI, 4: LO, 5: LL
Item Initial value Setting range Page
Zero calibration 0.000 -3.000 to 3.000 [mV/V] P. 14
Equivalent input calibration (rated output) 3.000 0.500 to 3.000 [mV/V] P. 14
Actual load calibration (capacity) 1000 0001 to 9999 P. 14
Decimal place 2: 0.00 0: None, 1: 0.0, 2: 0.00, 3: 0.000 P. 15
Indicator ID All 20H
20H to 60H, 7BH to 7EH
20 bytes of ASCII code
P. 15
Loadcell ID All 20H
20H to 60H, 7BH to 7EH
20 bytes of ASCII code
P. 15
