4 HOW TO CALIBRATION
15
HOW TO CALIBRATION
Chapter
4
4-1. Equivalent input calibration procedure
The equivalent input calibration uses the following procedure;
Set the decimal place. (omissible if no desired value is present)
Set the zero point of the strain gauge sensor.
Set the rated output vale and rating value of the strain gauge sensor.
4-2. Actual load calibration procedure
The actual load calibration uses the following procedure;
Set the decimal place. (Omissible if no desired value is present)
Set the zero point of the strain gauge sensor.
Set the span(gain) point of the strain gage sensor.
4-3. Decimal place
This function sets the Position of decimal point.
4-4. Equipment ID
F331 can be set Equipment ID for identification.
Equipment ID has Indicator ID and Loadcell ID.
Setting be 20 bytes (20H to 60H, 7BH to 7EH) of ASCII code.
Equivalent input calibration
Setting decimal place
Zero calibration
Actual load calibration
Setting decimal place
Zero calibration
