4 & 8 & 16 Channel DVR Operation manual Revision 1.0
Description:
1. VIDEO IN
z IN : CAMERA INPUT terminal. This is for CVBS signal input.
z OUT : LOOP OUT terminal. This is for other DVR connection or other device’s input
channel.
2. VIDEO OUT
z VIDEO : VIDEO OUT terminal. CVBS signal is exported.
z SPOT : SPOT VIDEO OUT TERMINAL. CVBS signal is exported..
3. USB
z This is USB memory stick terminal to back up HDD video screen.
z USB Mouse is available.
4. ETHERNET
z This is to connect 10/100 Base-T network connection port (RJ-45).
5. AUX/ALARM/SENSOR
z This is to connect AUX IN/OUT, Alarming device and sensor device. (DSUB-25 male
Connector)
z DC 5V power is provided to connect other devices.
6. RS-485
z 485 A Port : This is to connect PTZ device ( RS-485port).
z 485 B Port : Reserved
7. RS-232
z SERIAL : This is to connect RS-232 port on PC to use console function or for Quick installer.
(DSUB-9 male Connector)
8. S-VIDEO
z Standard S-VIDEO signal is exported.
9. VGA
