Controls and Indicators 067449-023 LX31/LX41 Electric and BiEnergy
Operator Manual Page 5
C
ONTROLS AND
I
NDICATORS
Figure 2:
Controls and Indicators
1
6 7
8
2
3
4
5
9
10
4*
2
1
3
7**
9
10
8
Outrigger Options
* Outrigger Switches and Outrigger Lights are installed
on outrigger equipped machines only.
** Outrigger selection is available on outrigger equipped
machines only.
5*
5*
4*
1 Steering Switch
2. Interlock Lever Switch
3. Control Lever
4. Outrigger Switches
5. Outrigger Indicator Lights
6. Emergency Stop Switch
7. Lift/Drive Switch
8. Drive Speed/Torque Selector Switch
9. Drive Enable Indicator
10. Key Switch
11. Glow Plug Button
12. Horn Button
6
11
1EmergencyStop
2. Platform/Chassis Switch
3. Raise Button
4. Brake Release Button
5. Lower Button
6. Key Switch
7. Start Button
8. Glow Plug Button
9. Hour Meter
Platform Controls
Chassis Controls
12
