Page 20 Operator Manual
067449-023 LX31/LX41 Electric and BiEnergy Specifications
S
PECIFICATIONS
Specifications subject to change without notice. Refer to the Service Manual for service and repair infor-
mation. Refer to the Parts Manual for illustrated parts breakdown. Hot weather or heavy use may reduce
performance. Meets or exceeds all applicable national safety requirements
ITEM LX31 LX41
Platform Size (Inside toeboards)
Standard 3,96 m x 1,73 m [156 in x 68 in.] 3,96mx1,73m[156inx68in.]
Slide-out Deck Extended 4,83 m x 1,73 [190in.x68in.] 4,83mx1,73[190 in. x 68 in.]
Max. Platform Capacity
Standard 907 kg [2,000 lbs.] 680 kg [1,500 lbs.]
With Rear Deck Option 794 kg [1750 lbs.] 567 kg [1,250 lbs.]
On Extension 227 kg [500 lbs.] 227 kg [500 lbs.]
Max. No. of occupants
Standard 5 people 5 people
With Rear Deck Option 5 people 4 people
Height
Working Height 11,45 m [37 ft. 6 in.] 14,34 m [47 ft. 3 in.]
Max. Platform Height 9,45 m [31 ft.] 12,34 m [40 ft. 6 in.]
Min. Platform Height 1,43 m [56.3 in.]1,66m[65.3 in.]
Drivable Height 9,45 m [31 ft.] 12,34 m [40 ft. 6 in.]
Dimensions
Weight, Standard Electric
BiEnergy
4586 kg [10,110 lbs.]
4745 kg [10,461 lbs.]
5298 kg [11,680 lbs.]
5457 kg [12,031 lbs.]
Weight, Dual Deck Electric
BiEnergy
4917 kg [10,840 lbs.]
5076 kg [11,191 lbs.]
5629 kg [12,410 lbs.]
5788 kg [12,760 lbs.]
Overall Width 2,29 m [90 in.]2,29m[90 in.]
Overall Height, guardrails up 2,53 m [99.8 in.]2,76m[109 in.]
Overall Height, guardrails lowered 1,64 m [64.5 in.]1,87m[73.5 in.]
Overall Length, deck in 4,02 m [160 in.]4,02m[160 in.]
Overall Length, deck extended 4,89 m [192 in.]4,89m[192 in.]
Surface Speed
Platform Lowered 0 to 5,0 km/h [0to3.1mph] 0to5,0km/h[0to3.1mph]
PlatformRaised 0to0,48km/h[0to0.5mph] 0 to 0,48 km/h [0to0.5mph]
System Voltage 48 Volt DC 48 Volt DC
Hydraulic Tank Capacity 107 liters [28.3USGallons] 107 liters [28.3 US Gallons]
Maximum Hydraulic System Pressure 207 bar [3000 psi] 207 bar [3000 psi]
Hydraulic Fluid
Normal Temperature: above 0° C [32° F] ISO #46 ISO #46
Low Temperature: below 0° C [32° F] ISO #32 ISO #32
Extreme Temperature: below -17° C [0° F] ISO #15 ISO #15
Lift System One Single Stage Lift Cylinder One Single Stage Lift Cylinder
Lift Speed Raise: 50 sec. Lower: 52 sec. Raise: 57 sec. Lower: 60 sec.
Power Source Electric
BiEnergy includes
Eight 6V 350 AH Batteries
Diesel12HPKubota
Eight 6V 350 AH Batteries
Diesel 12 HP Kubota
Drive Control Proportional Proportional
Control System Smooth one-hand Joystick Smooth one-hand Joystick
Horizontal Drive Two Electric Wheel Motors Two Electric Wheel Motors
Tires 10-16.5 NHS 8 Ply 10-16.5 NHS 8 Ply
Tire Air Pressure 5,2 bar [75 psi.]5,2bar[75 psi.]
Parking Brakes Dual Disc, Spring Applied, Hydraulic Release Dual Disc, Spring Applied, Hydraulic Release
Turning Radius (inside) 1,22 m [48 in.]1,22m[48 in.]
Maximum Gradeability 17° [30%]17°[30%]
Wheel Base 2,9 m [114.5 in.]2,9m[114.5 in.]
Ground Clearance 0,24 m [9.5 in.]0,24m[9.5 in.]
Guardrails
1.1 m [43.5 in.] high,
Fold Down with gate.
1.1 m [43.5 in.]high,
Fold Down with gate.
Noise Level BiEnergy Model
