Towing or Winching 067449-023 LX31/LX41 Electric and BiEnergy
Operator Manual Page 11
T
OWING
OR
W
INCHING
Perform the following only when the machine will not operate under its own power and it is necessary to
move the machine or when winching onto a transport vehicle (see “Transporting the Work Platform” on
page 13).
CAUTION
DO NOT tow or winch the machine faster than 0,3 m/s (1 ft./s). Faster speeds will damage drive
components and void the warranty.
P
ARKING
B
RAKE
R
ELEASE
Figure 5:
Parking Brake Release
WARNING
!
!
Never operate the work platform with the parking brakes
released. Serious injury or damage could result.
Never release the brakes if the machine is on a slope.
Chock the wheels before releasing the parking brakes.
Hook the machine to a towing vehicle before releasing the
parking brakes.
1. Turn the Chassis/Platform/Brake Release switch to the Brake
Release position.
• Alarm will sound
2. Momentarily push the Brake Release button.
3. The machine will now roll when pushed or pulled.
4. For normal operation, turn the Platform/Chassis/Brake Release switch to Platform.
5. Verify that the parking brakes have engaged before the machine is operated.
A
FTER
U
SE
E
ACH
D
AY
1. Ensure that the platform is fully lowered.
2. Park the machine on level ground, preferably under cover, secure against vandals, children or unautho-
rized operation.
3. Turn the key switch to OFF and remove the key to prevent unauthorized operation.
Platform/Chassis/Brake Release Switch
Brake Release Button
