Upright X Series Service & Parts Manual

7-20
7.2
Illustrated Parts Breakdown
X20N/X20W/X26N/X31N Work Platform
Section
BASIC ASSEMBLY
X20W
66051-001
ITEM PART DESCRIPTION QTY.
1 66052-001 CHASSIS ASSEMBLY 1
2 66053-000 SCISSOR ASSEMBLY 1
3 66292-000 PLATFORM WELDMENT 1
4 11248-006 NUT 3/8-16 16
5 11240-006 WASHER 3/8 FLAT 8
6 66189-000 WEAR PAD 1/4 16
7 66189-001 WEAR PAD 3/8 2
8 66189-004 WEAR PAD 1/8 2
9 66191-001 SLIDE BLOCK (BOTTOM) 2
10 61796-099 GROMMET .63FT
11 66183-001 BEARING 2
12 66222-001 MOUNTING PIN 4
13 66222-002 MOUNTING PIN 4
14 66191-000 SLIDE BLOCK 4
15 11287-032 SCREW SOC HD CAP 3/8-16 X 4 LG 8
16 11254-032 SCREW HHC 3/8-16 X 4 LG 8 W
