Upright X Series Service & Parts Manual

X-Series Work Platform 2-1
Machine Preparation
Section
2.2 Preparation For Shipment
1. Fully lower the platform.
2. Disconnect the battery negative (-) lead from the
battery terminal (Figure 2-1).
3. Band the Platform Assembly to the Chassis.
Read, understand and follow all safety rules and
operating instructions before attempting to operate
the machine.
2.1 Preparation for Use
STAND CLEAR when cutting the metal
banding to avoid being cut when the
banding snaps back.
1. Remove the metal banding from the machine.
2. Lift the front of the machine and remove banding
and blocks from front wheels.
3. Lower machine.
4. Connect the negative battery lead terminal (Figure 2-
1).
2.1
Figure 2-1: Battery Module
Negative Battery Terminal
