Upright X Series Service & Parts Manual

X-Series Work Platform
Introduction & Specifications
Section
1-1
1.0 Introduction
PURPOSE
This manual provides illustrations and instructions for
the operation and maintenance of the X-Series Work
Platform manufactured by UpRight, Inc. Selma, Califor-
nia. (See Figure 1-1).
SCOPE
This manual includes both operation and maintenance
responsibilities concerning the X-Series Work Platform’s
readiness. The Maintenance Section covers scheduled
maintenance, troubleshooting, repair, adjustment and
replacement.
Figure 1-1: X-Series Work Platform
1.1 General Information
DESCRIPTION
The X-Series Work Platform is a self-propelled aerial
work platform designed to be used as a means of
elevating personnel and equipment and to provide a
mobile work platform. They are designed to provide
mobility with the platform in a raised or lowered posi-
tion. Travel with the platform elevated is limited to the
low speed range.
PURPOSE AND LIMITATIONS
The objective of the X-Series Work Platform is to pro-
vide a quickly deployable, self-propelled, variable
height work platform. The elevating function shall only
be used when the work platform is on a firm level work
area. The work platform is intended to be self-propelled
when in relatively close proximity to the work area.
1.0
1. Platform/Guardrails
2. Controller
3. Elevating Assembly
4. Chassis
1
2
3
4

Upright X Series Specifications

General

Brand	Upright
Model	X Series
Category	Lifting Systems
Language	English
