X-Series Work Platform 4-1
Maintenance
Section
4.0
4.0 Introduction
This section contains instructions for the maintenance of
the X-Series Work Platform. Procedures for the opera-
tional checkout adjustment, scheduled maintenance,
and repair/removal are included.
Referring to
Section 3.0
will aid in understanding the
operation and function of the various components and
systems of the X-Series Work Platform and help in
diagnosing and repair of the machine.
SPECIAL TOOLS
The following is a list of special tools that are required to
perform certain maintenance procedures. These tools
may be purchased from your dealer.
Description Part Number
Inclinometer 10119-000-00
Gauge, 0-3000 psi 14124-030-00
Gauge, 0-6000 psi 14124-060-00
Fitting, Quick Disconnect 63965-002-00
4.1 Preventative Maintenance
(Table 4-1)
The complete inspection consists of periodic visual and
operational checks, together with all necessary minor
adjustments to assure proper performance. Daily in-
spection will prevent abnormal wear and prolong the
life of all systems. The inspection and maintenance
schedule is to be performed at regular intervals. Inspec-
tion and maintenance shall be performed by personnel
who are trained and familiar with mechanical and
electrical procedures. Complete descriptions of the
procedures are in the text following the table.
Before performing preventative mainte-
nance familiarize yourself with the opera-
tion of the machine.
Always use the elevating assembly brace
whenever it is necessary to enter the
scissor assembly when the Platform is
elevated.
The Preventative Maintenance Table has been designed
to be used for machine service and maintenance repair.
Please copy the following page and use this table as a
checklist when inspecting a machine for service.
