Upright X Series Service & Parts Manual

4-2 X-Series Work Platform
Maintenance
Section
COMPONENT INSPECTION OR SERVICES INTERVAL Y N R
Battery Check electrolyte level Daily
System Check battery cable condition Daily
Charge batteries Daily
Check charger condition & operation Daily
Check specific gravity 50h/30d
Clean exterior 250h/6m
Clean terminals 250h/6m
Hydraulic Oil Check oil level Daily
Change filter 250h/6m
Clean Reservoir Breather/Cap 250h/6m
Drain and replace oil (ISO #46) 1000h/2y
Hydraulic Check for leaks Daily
System Check hose connections 50h/30d
Check for exterior wear 50h/30d
Emergency Open the emergency lowering
Hydraulic valve and check for
System serviceability Daily
Controller Check condition & operation Daily
Control Check the exterior of the cable
Cable for pinching, binding or wear Daily
Platform Check fasteners for proper torque Daily
Deck and Check welds for cracks Daily
Rails Check condition of deck Daily
Check entry way closure Daily
Hydraulic Check for hose fitting leaks Daily
Pump Wipe clean 50h/30d
Check for leaks at mating surfaces 50h/30d
Check mounting bolts for
proper torque 50h/30d
Drive Motors Check for operation and leaks Daily
Steering Lubricate pivot pins 250h/6m
System Lubricate king pins 250h/6m
Check steering cylinder for leaks 50h/30d
Check hardware & fittings
for proper torque 250h/6m
Elevating Inspect for structural cracks Daily
Assembly Check pivot bearings for wear 50h/30d
Check pivot pin mounting bolts
for proper torque 50h/30d
Check Scissor Arms for bending 250h/6m
Chassis Check hoses for pinch or
rubbing points Daily
Check welds for cracks Daily
Check tires for damage Daily
Check wheel bolts/nuts for proper
torque Daily
Check component mounting
for proper torque 250h/6m
Lift Check cylinder rod for wear 50h/30d
Cylinder Check pivot pin retaining rings 50h/30d
Check seals for leaks 50h/30d
Check pivot points for wear 50h/30d
Check fittings for proper torque 50h/30d
Entire Perform pre-operation inspection Daily
Unit Check for and repair collision damage Daily
Lubricate 50h/30d
Check fasteners for proper torque 250h/6m
Check for corrosion-remove
and repaint 250h/6m
Labels Check for peeling, missing, or
unreadable labels & replace Daily
4.1
Preventative Maintenance Table Key
Interval
Daily=each shift or every day
50h/30d=every 50 hours or 30 days
250h/6m=every 250 hours or 6 months
1000h/2y=every 1000 hours or 2 years
Y=Yes/Acceptable
N=No/Not Acceptable
R=Repaired/Acceptable
Preventative Maintenance Report
Date: ____________
Owner: _______________________________________
Model No: _____________ Serial No: _____________
Serviced By: ___________________________________
Service Interval: ________________________________
Table 4-1: Preventative Maintenance
