Upright X Series Service & Parts Manual

7-26
7.2
Illustrated Parts Breakdown
X20N/X20W/X26N/X31N Work Platform
Section
CHASSIS ASSEMBLY
X20N
66002-010
ITEM PART DESCRIPTION QTY.
1 11248-008 NUT HEX 1/2-13 UNC 8
2 11248-006 NUT HEX 3/8-16 UNC 5
3 11248-012 NUT HEX 3/4-10 UNC 3
4 11273-006 NUT JAM 3/8-16 2
5 66773-000 HUB ASSY 2
6 11254-008 SCREW HHC GR5 3/8-16 UNC X 1 4
7 11775-011 CONE BEARING 4
8 11254-016 SCREW HHC GR5 3/8-16 UNC X 2 1
9 11256-024 SCREW HHC GR5 1/2-13 UNC X 3 8
10 11254-012 SCREW HHC GR5 3/8-16 UNC X 1 1/2 4
11 11254-010 SCREW HHC GR5 3/8-16 UNC X 1 1/4 2
12 11258-024 SCREW HHC GR5 3/4-10 UNC X 3 1
13 11240-006 WASHER 3/8 FLAT 4
14 11287-022 SCREW SOCKET HD 3/8-16 X 2 3/4 2
15 05104-000 SEAL GREASE 2
16 11782-008 BEARING (STEER) 2
17 05078-000 CAP DUST 2
18 11705-016 SCREW SET 3/8-16 X 1 2
19 11776-004 CUP BEARING 4
20 11934-024 FITTING 4
21 11757-007 PIN COTTER 5/8 1
22 11757-010 PIN COTTER 3/4 4
23 27931-074 BEARING (STEERING) 4
24 11753-012 PIN COTTER 1/8 X 1 1/2 4
25 11274-016 NUT 1-14UNF SLOTTED HEX 4
26 61796-099 GROMMET 1.25FT
27 61692-099 GROMMET 1.38FT
28 66602-000 CYLINDER STEERING 1
* 66602-010 SEAL KIT, STEERING CYLINDER 1
29 61817-001 MOTOR HYDRAULIC 2
* 61817-010 SEAL KIT, HYDRAULIC MOTOR 1
30 61846-001 WHEEL & TIRE 4
31 66604-000 BRAKE CYLINDER 1
* 66604-010 SEAL KIT, BRAKE CYLINDER 1
32 11934-003 FITTING 90 O RING BOSS 6MB 4MJ 4
33 63664-007 ORIFICE 1
ITEM PART DESCRIPTION QTY.
34 66717-000 WELDMENT - CHASSIS 1
35 11239-016 WASHER 1 DIA FLAT ASTM 2
36 66702-000 SLIDE PAD, STEERING LINK 2
37 66774-000 WELDMENT - LADDER BRACKET 1
38 66774-001 WELDMENT - LADDER BRACKET 1
39 14996-012 WASHER SAE 3/4 DIA 2
40 66325-000 HUB - FRONT 2
41 11782-009 BUSHING 2
42 63559-006 BOLT SHOULDER 3/8 X 2 1
43 11848-009 CLEVIS PIN 5/8 X 2 1
44 62642-006 BUSHING 2
45 66159-001 STEERING LINK WELDMENT L.H. 1
46 66190-000 BEARING - STRIP 2
47 26553-012 RIVET 3/16 DIA X 1 1/8 GRIP 2
48 62642-008 BUSHING 3
49 66311-001 WELDMENT - STEERING ANGLE LH 1
50 66312-001 WELDMENT - STEERING ANGLE RH 1
51 66313-001 WELDMENT - BELL CRANK 1
52 66737-000 PIN, BELL CRANK 1
53 66158-001 STEERING LINK WELDMENT R.H. 1
54 66307-000 WELDMENT - LADDER 1
55 66796-000 WELDMENT, CHARGER GUARD 1
56 66304-001 WELDMENT - BRAKE TUBE 1
57 66305-001 WELDMENT - BRAKE 2
58 11848-041 CLEVIS PIN 3/4 X 2 2
59 11246-005 NUT HEX ESNA 5/16-18 1
60 13336-011 FITTING GREASE 4
61 66728-000 WELDMENT, BRAKE ADJUSTMENT 1
62 16759-015 ROD, BRAKE RELEASE 1
63 62642-001 BEARING 1
64 02186-000 WASHER 3/16 FLAT 2
65 66792-001 WASHER 3/4 BELLVILLE 2
66 27931-071 BEARING (BRAKE) 2
67 14122-003 WHEEL BOLT 1/2-20 X 1 16
* Not shown
