Basic Operation
3-20
Follow the steps as below for stapling.
1 Press the Copy key.
2 Place the originals on the platen.
NOTE: When performing Mixed Size Stapling, refer to
Mixed Size Originals on page 4-6.
3 Press [Org./Paper/Finishing] and then [Staple/
Punch].
4 Select the staple position.
NOTE: To use saddle stitching, press [Saddle Stitch].
When placing originals, be sure to place the cover
page at the bottom. For more information on saddle
stitching, refer to Booklet on page 4-20.
5 Press [Original Orientation] to choose orientation of
the originals, either [Top Edge on Top] or [Top Edge
on Left]. Then press [OK].
6 Press [OK].
7 Press the Start key. Copying begins.
Mixed Size Stapling
Even with mixed paper sizes, if the sizes have the same width or same length as shown in the combinations
below, the output can be stapled. The maximum number of sheets that can be stapled is 30.
• A3 and A4
• B4 and B5
• Ledger and Letter
• Ledger and Letter-R
• 8K and 16K
To Next Page
