Troubleshooting
12-39
12
Optional Job Separator
Follow the steps below to clear paper jams in the optional job separator.
Inner Job Separator
1 If jammed paper is seen through the paper ejection
slot of the inner job separator, pull it toward your
side to remove it.
If the paper tears, remove every loose scrap from
inside the machine.
2
Pull up right cover 1 lever and open the right cover 1.
3 Press the lever and open the fuser cover.
CAUTION: The fixing unit is extremely hot. Take
sufficient care when working in this area, as there is a
danger of getting burned.
4 Remove the jammed paper.
If the paper tears, remove every loose scrap from
inside the machine.
To Next Page
